標準現貨款尺寸：

長*深*高：1200*900*750（雙聯）

               1800*900*750（三聯）

可根據現場需求靈活拼接使用

技術說明Technical specification
獨特的結構設計：控制臺在設計上符合人體工程學參數，并以最大限度提高操作員的舒適度；使用模塊化的框架體系，可以創建不同的配置和可視化的布局，在增減模塊時不會影響控制臺的結構完整性，使未來重建或改造更加容易；采用全拼裝式架構，使運輸及安裝更加簡便，僅使用一把螺絲刀即可完成整個安裝過程
牢固的型材背板：控制臺背板采用高強度鋁型材，鋁型材橫截面尺寸是根據此款式控制臺架構特殊定制，可安裝特制的LCD支架、工作燈、電話架、文件架等，高度可根據工作環境選用200mm高度和300mm高度
超大的存儲空間：控制臺每組可輕松容納4臺PC主機或20U的標準19設備
合理的布線方式：控制臺后部有通長的毛刷走線孔，桌面顯示器數據線及燈線由此進入控制臺內部，在后臺面的下部和控制臺的底部均設有橫向通長的理線槽，讓每個電源線，數據線和地面的布線分開，同時還提供了雙條理線道，可強弱電分開，理線槽上有足夠的空間，根據需要就近安裝電源插座和多個信息點，安裝合理的走線方式使整體線路布局整潔、美觀
完美的散熱效果：利用氣流交換的原理，分別在控制臺前后門設計了散熱孔，底部和前門上部預留了較大散熱空間，充分保障設各安全高效運轉
Unique structural design of the console in design accord with human body engineering and to maximize operating parameters The comfort of using a modular framework can create different configuration and the layout of the visualization in Increase or decrease when the module will not affect the structural integrity of the console to make future reconstruction or reform more easy to use Truss structure, make the transportation and installation easier using only a screwdriver can complete the whole installation process. Solid material back the console back high strength aluminum extrusions cross section size is according to this Type console architecture special custom install special LCD bracket, working lamp telephone rack, files etc Degrees can be selected according to the work environment 200 mm and 300 mm high level. Large storage space console each group can easily accommodate 4 PC host or standard 19 "equipment of 20 u. Reasonable wiring way at the back of the console with tong long brush go line holes by desktop monitor cable and light line This into the console internal in the background to the bottom and the bottom of the console has transverse flux long slot Let each power cable from the wiring of the ground at the same time also provides a double order line can be strong and weak electricity points Open cut slot on enough space according to the need to install the power socket and multiple information point installation is reasonable Linear way make integral circuit layout clean and beautiful. Perfect heat dissipation effect by using the principle of thermal exchange respectively in the console QianHouMen designed cooling hole and the front door at the bottom of the upper thermal dissipation space has been greatly to fully guarantee the safe and efficient operation
